72072 Split Nut
This part is a replacement split nut for select Hot Spring hot tub models. The 2" split nut comes with screws to secure it together.
This part is used to replace compression fitting nuts or pump union nuts. Compatible with a variety of the 1993 to 2021 Hot Spring Highlife, Hot Spot, and Tiger River spa models.
| Item | Decsription | Part # |
| 1 | JET PUMP, 1.65HP 1SP DUAL 60HZ | 71699 |
| 2 | GROMMET, JET PUMP BASE 97-C | 72349 |
| 3 | WASHER FLT 5/16X3/4 SS | 30413 |
| 4 | SCW 1/4-20X1-1/2 MS PH PLP SS | 30018 |
| 5 | POWER CORD | N/A |
| 6 | EXHAUST HOSE, JET PUMP 01-C | 72344 |
| 7a | UNION, PUMP | 1119401 |
| 7b | 2" SOC.90 DEG SWEEP PUMP UNION | 301488 |
| 7c | 429-020 CPLG 2IN SLXSL | 30665 |
| 7d | O-RING, COMPRESSION FITTING | 34447 |
| 7e | HOSE, PVC FLEX 2" X 36" | 70308 |
| 7f | FITTING COMPRESS 2 W/O-RING | 71036 |
| 7g | FITTING COMPRESS 2X1.5 W/ORING | 71037 |
| 7h | FITTING COMPRE 1.5W/O-RNG | 71038 |
| 7i | SPLIT NUT, 2" JET PUMP | 72072 |
| 8a | SHAFT SEAL ASSEMBLY | 71447 |
| 8b | SEAL, SHAFT LX JET PUMP #3536 | 77363 |
| 9a | ADAPTER 1/2IN HOSE 0675-063 | 33732 |
| 9b | ADAPTER ELL, 1/4-MIPT 1/2-BARB | 39438 |
| 10a | WET END 1.65 HP 60HZ ST D | 72994 |
| 10b | WET END 1.5/1.65 HP 60 HZ L-03 | 77711 |
| Item | Description | Part # |
| 1 | 45 Degree Pump Union | 1119401 |
| 2 | 2 Inch Split Nut W/Screws | 72072 |
| 3 | 2 Inch O-Ring | 34447 |
| 4 | 2 Inch Flexible Hose | 70308 |
| 5 | 2 Inch Coupling | 30665 |
| Item | Description | Part # |
| 1 | JET PUMP, 2.5HP 1SP 230V 60HZ | 72196 |
| 2A | WET END 2.5 HP 60HZ ST D | 72996 |
| 2B | WET END 2.5 HP 60 HZ, L-03 | 77713 |
| 3 | DRAIN FITTING, JET PUMP 1/4IN | 32267 |
| 4A | UNION, PUMP | 1119401 |
| 4B | 2" SOC.90 DEG SWEEP PUMP UNION | 301488 |
| 4C | 429-020 CPLG 2IN SLXSL | 30665 |
| 4D | O-RING, COMPRESSION FITTING | 34447 |
| 4E | HOSE, PVC FLEX 2" X 36" | 70308 |
| 4F | ITTING COMPRESS 2 W/O-RING | 71036 |
| 4G | FITTING COMPRESS 2X1.5 W/ORING | 71037 |
| 4H | FITTING COMPRE 1.5W/O-RNG | 71038 |
| 4I | SPLIT NUT, 2" JET PUMP | 72072 |
| 5A | SHAFT SEAL ASSEMBLY | 71447 |
| 5B | SEAL, SHAFT LX JET PUMP #3536 | 77363 |
| 6 | GROMMET, JET PUMP BASE 97-C | 72349 |
| 7 | WASHER FLT 5/16X3/4 SS | 30413 |
| 8 | SCW 1/4-20X1-1/2 MS PH PLP SS | 30018 |
| 9 | KIT, PUMP CORD 14/3 1SPD STRS | 72462 |
| 10 | EXHAUST HOSE, JET PUMP 01-C | 72344 |
